移動生物偵檢儀

RAPM移動式生物快速偵檢儀

產品型號：RAMP

產地：加拿大

RAMP生物快速檢測系統是一款層析免疫檢定裝置，能夠快速提供有關生物威脅的診斷結果。RAMP可以用于測定幾乎所有的免疫活性物質。該系統標準配置包括用于探測炭疽桿菌、天花病毒、蓖麻毒素及肉毒毒素的檢測試劑盒。

受美國國土安全部（DHS）委托，經美國官方分析化學師協會（AOAC）、疾病預防控制中心（CDC）及軍方等十二家獨立實驗室測試，在眾多產品中， RAMP生物快速檢測系統是通過標準的炭疽現場檢測的系統。

應用領域

應急突發事件現場

重要活動、群體集會場所

車載、艦載使用

區域監測系統

衛生疾控中心

機場、海關

技術參數

產 地：加拿大

工作原理：干式免疫熒光檢測法

檢測功能：炭疽、蓖麻毒素、肉毒素、天花毒素（痘病毒）

檢測精度：炭疽桿菌4ng(4000個孢子)；肉毒素5ng；蓖麻毒素10ng；天花毒素3.6ng

供電方式：可外接220V交流電；內置充電電池可獨立檢測100次

數據輸出：RS-232

尺 寸：(長) x (寬) x (高)

重 量：

工作溫度：-10 - +

防護等級：ZEC 6醫學電磁兼容設備，CAN/CSA 601.1，FCC CFR47 Part 15/B

RAMP? READER HIGHLIGHTS

A true point of care testing solution

A fully portable (battery and/or AC power), lightweight reader; runs up to 100 tests on one charge

Self-diagnostic and internal quality control checks

No calibration or maintenance required

Menu allows for RAMP? Reader customization

Multiple access levels for enhanced security including operator lockout

Internal electronic quality control (IQC) and external liquid QC (LQC) available

Stores up to 500 sample, 65 IQC results and 35 LQC results

Stores lot information – up to and including 50 lots

Data can be exported to a computer or LIS

Barcode wand and printer accessories also available for the RAMP? Reader

RAMP? READER OPERATION PRINCIPLES

The RAMP? Reader uses proprietary software to read pre-programmed lot cards

The lot card is inserted into the RAMP? Reader prior to running a new test lot and enables the RAMP? Reader to automatically determine the test that is being run and calibrates the RAMP? Reader on a lot-specific basis. No user calibration required!

The RAMP? Reader rejects used or expired cartridges or insertion of a new cartridge without previous lot card entry

The test cartridge is prepared, as per the Instructions for Use, and inserted into the RAMP? Reader

If the RAMP? Reader detects any errors, a clear error message will display on-screen instead of reporting a wrong result

The RAMP? Reader calculates the RAMP? Ratio to correct for sources of variability; time to result is ~15 minutes

產品特點

快速、靈敏、精準、便攜、大容量存儲、現場使用

高特異性：不相關毒素，結果均為陰性

樣本多樣：粉末、液體、印痕均可

內部質控：獨有內部質量控制帶，準確消除系統誤差

批間質控：高精度批號卡，消除批次間差異

操作簡易：簡單培訓即可獨立操作

結果輸出：可存儲500條檢測結果，液晶屏顯示，

可選打印機打印，亦可連接實驗室信息系統(LIS)
